| Количество SATA | 2 |
|---|---|
| Количество каналов | 32 |
| Бренд | Uniview |
| Запись с разрешением до | 8 Мп |
| Максимальная емкость одного HDD | 24 ТБ |
| Количество IP каналов | 4 |
Внимание: Изображения и характеристики товара могут отличаться от реальных параметров.
Пожалуйста, уточняйте информацию у менеджера.
Пожалуйста, уточняйте информацию у менеджера.
XVR302-32Q3 видеорегистратор
166 300 ₸
<table width="100%">
<tbody>
<tr>
<td width="30%">Video/Audio Input</td>
<td width="70%">Description</td>
</tr>
<tr>
<td>IP Video Input</td>
<td>4-ch</td>
</tr>
<tr>
<td>Analog Video Input</td>
<td>32-ch, BNC</td>
</tr>
<tr>
<td>Max IP Video Input</td>
<td>36-ch</td>
</tr>
<tr>
<td>Supported Analog Camera Types</td>
<td>Support AHD input: <br>8MP@15fps<br>5MP@20fps<br>4MP@30fps<br>1080P@30fps<br>720P@30fps<br>Support TVI input:<br>8MP@15fps<br>5MP@20fps<br>4MP@30fps<br>1080P@30fps<br>720P@30fps<br>Support CVI input:<br>8MP@15fps<br>5MP@25fps<br>4MP@30fps<br>1080P@30fps<br>720P@30fps<br>Support CVBS input</td>
</tr>
<tr>
<td>BNC Audio Input</td>
<td>32-ch, channel audio</td>
</tr>
<tr>
<td>RCA Audio Input</td>
<td>1-ch</td>
</tr>
<tr>
<td>Video/Audio Output</td>
<td>Description</td>
</tr>
<tr>
<td>HDMI Output</td>
<td>HDMI:4K(3840×2160)/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz</td>
</tr>
<tr>
<td>VGA Output</td>
<td>VGA:<br>1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz</td>
</tr>
<tr>
<td>BNC Video Output</td>
<td>1-ch</td>
</tr>
<tr>
<td>RCA Audio Output</td>
<td>1-ch</td>
</tr>
<tr>
<td>Live View Display</td>
<td>HDMI/VGA: 1/4/6/8/9/25/36</td>
</tr>
<tr>
<td>Encoding/Decoding</td>
<td>Description</td>
</tr>
<tr>
<td>Recording Resolution</td>
<td>8MP Lite/5MP Lite/4MP Lite /1080P/720P/D1</td>
</tr>
<tr>
<td>Recording Frame Rate</td>
<td>Main stream: 8MP Lite@8fps Sub stream: D1@8fps<br>Main stream: 5MP Lite@12fps Sub stream: D1@12fps<br>Main stream: 4MP Lite@15fps Sub stream: D1@15fps<br>Main stream: 1080P@15fps Sub stream: D1@15fps<br>Main stream: 720P@30fps Sub stream: D1@30fps</td>
</tr>
<tr>
<td>Audio Sample Rate</td>
<td>8KHz,16 bit per channel</td>
</tr>
<tr>
<td>Audio Bit Rate</td>
<td>64Kbps per channel</td>
</tr>
<tr>
<td>Decoding Capability</td>
<td>Analog: 16 x 8MP Lite@8, 16x 5MP Lite@12, 16x 4MP Lite@15, 16 x 1080P@15, 16 x 720@30<br>IP: 16 x 720P@30, 8 x 1080P@30, 4 x 4MP@30, 2 x 8MP@30</td>
</tr>
<tr>
<td>Num of Concurrent Playback in Local</td>
<td>16-ch</td>
</tr>
<tr>
<td>Coaxial Cable</td>
<td>Description</td>
</tr>
<tr>
<td>Audio over Coaxial Cable(Form)</td>
<td>32-ch, One-way Audio(only for Uniview CVI protocol cameras)</td>
</tr>
<tr>
<td>Two-way Audio</td>
<td>Description</td>
</tr>
<tr>
<td>Two-way Audio</td>
<td>1-ch, RCA(Using the audio input and output)</td>
</tr>
<tr>
<td>Analog Snapshot</td>
<td>Description</td>
</tr>
<tr>
<td>FTP/Schedule/Event Snapshot</td>
<td>Schedule/FTP/Event snapshot:32-ch snapshot, up to 704*576 resolution</td>
</tr>
<tr>
<td>Network</td>
<td>Description</td>
</tr>
<tr>
<td>Incoming Bandwidth</td>
<td>80Mbps (Up to 144Mbps after all analog channel conversion)</td>
</tr>
<tr>
<td>Outgoing Bandwidth</td>
<td>160Mbps</td>
</tr>
<tr>
<td>Remote Users</td>
<td>128</td>
</tr>
<tr>
<td>Protocols</td>
<td>TCP/IP;P2P;UPnP;DHCP;HTTP;HTTPS;DNS;DDNS;SMTP;NTP</td>
</tr>
<tr>
<td>Browser(Plugin)</td>
<td>Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above)</td>
</tr>
<tr>
<td>Smart</td>
<td>Description</td>
</tr>
<tr>
<td>Analog Smart by XVR</td>
<td>Ultra Motion Detection(UMD)</td>
</tr>
<tr>
<td>IP Smart by IPC</td>
<td>Face Detection;Defocus Detection;Scene Change Detection;Object Removed;Object Left Behind;Auto Tracking</td>
</tr>
<tr>
<td>VCA Search</td>
<td>Face Search;Behavior Search</td>
</tr>
<tr>
<td>Smart Functions by XVR</td>
<td>16-ch(UMD)</td>
</tr>
<tr>
<td>Alarm</td>
<td>Description</td>
</tr>
<tr>
<td>General Alarm</td>
<td>Motion</td>
</tr>
<tr>
<td>Alert Alarm</td>
<td>IP Conflict;Network Disconnected;Disk offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot Abnormal</td>
</tr>
<tr>
<td>Hard Disk</td>
<td>Description</td>
</tr>
<tr>
<td>SATA</td>
<td>2 SATA interfaces</td>
</tr>
<tr>
<td>Capacity</td>
<td>Up to 8TB for each HDD (The maximum HDD capacity varies with environment temperature)</td>
</tr>
<tr>
<td>External Interface</td>
<td>Description</td>
</tr>
<tr>
<td>Network Interface</td>
<td>1 RJ45 10M/100M/1000M self-adaptive Ethernet Interface</td>
</tr>
<tr>
<td>USB</td>
<td>Rear panel: 1 x USB3.0;Front panel: 1 x USB2.0</td>
</tr>
<tr>
<td>RS485</td>
<td>1</td>
</tr>
<tr>
<td>Alarm In</td>
<td>4-ch</td>
</tr>
<tr>
<td>Alarm Out</td>
<td>1-ch</td>
</tr>
<tr>
<td>Power Supply</td>
<td>DC 12V/5A</td>
</tr>
<tr>
<td>Working Environment</td>
<td>Description</td>
</tr>
<tr>
<td>Working Temperature</td>
<td>-10°C ~ + 55°C ( +14°F ~ +131°F )</td>
</tr>
<tr>
<td>Working Humidity</td>
<td>≤ 90% RH(non-condensing)</td>
</tr>
<tr>
<td>Power Consumption (without HDD)</td>
<td>≤ 38W</td>
</tr>
<tr>
<td>Dimensions</td>
<td>Description</td>
</tr>
<tr>
<td>Weight (without HDD)</td>
<td>≤2.6 Kg ( 5.72lb )</td>
</tr>
<tr>
<td>Dimensions</td>
<td>380mm ×326mm× 53mm (15.0" × 12.8"×2.1")</td>
</tr>
<tr>
<td>Certification</td>
<td>Description</td>
</tr>
<tr>
<td>Certification</td>
<td>CE, FCC, UL, RoHS, WEEE</td>
</tr>
<tr>
<td>CE</td>
<td>EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035</td>
</tr>
<tr>
<td>FCC</td>
<td>Part15 Subpart B</td>
</tr>
</tbody>
</table>
Характеристики
Количество SATA: 2
Количество каналов: 32
Бренд: Uniview
Запись с разрешением до: 8 Мп
Максимальная емкость одного HDD: 24 ТБ
Количество IP каналов: 4
