UAC-B112-F28-W-X уличная HD видеокамера

  UAC-B112-F28-W-X UAC-B112-F40-W-X Camera Max Resolution 2 MP Sensor Size 1/3.0″ CMOS Min. Illumination 0.01 lux (F1.6, AGC ON)0 lux (white light on) Lens Focus 2.8 mm 4.0 mm Lens Mount M12 Angle of View (H) 100.9° 82.5° Angle of View (V) 56.5° 42.1° Angle of View (D) 121.8° 98.6° Illuminator Illuminator Number One white-light illuminator Illumination Distance 20m Lifetime ≥ 60000 hours Video Resolution 1080P: 1920(H)×1080(V)720P: 1280(H) ×720(V) Frame Rate TVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fpsAHD: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fpsCVI: 1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fpsCVBS: PAL, NTSC Shutter Time PAL: 1/25 s-1/50000 s, NTSC: 1/30 s-1/50000 s Image Exposure Mode Four modes: Global (default), BLC, HLC, DWDR Day/Night 24/7 color images Digital Noise Reduction 2D/3D White Balance Two modes: Auto (default), Manual WDR DWDR Flip Supports 180°horizontal flip, 180°vertical flip Interface Power Interface 5.5 mm Power Interface Video Output BNC, supports TVI/AHD/CVI/CVBS Operating Environment Temperature -30 ℃ to 60 ℃ (-22 ℉ to 140 ℉) Humidity ≤ 95% RH (non-condensing) Surge Protection 4 KV for power, 4 KV for video output interfaces General Power DC 12 V±25% Power Consumption MAX 2.0W Mount Corner Mount, Pole Mount Dimensions 142mm*63mm*65mm (L*W*H) Material Graphene + Plastic Weight 145g(0.32lb) OSD Menu Language 11 Languages: English, German, Spanish (Latin America), French, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Turkish Certification EMC CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B) Safety CE-LVD (EN 62368-1) Environment CE-RoHS (2011/65/EU; (EU) 2015/863); WEEE (2012/19/EU) Protection IP67 (IEC 60529)
