IPC264SA-DZK Уличная IP видеокамера

<table width="100%">
<tbody>
<tr>
<td colspan="5" width="70%">IPC264SA-DZK</td>
</tr>
<tr>
<td>Camera</td>
</tr>
<tr>
<td>Sensor</td>
<td colspan="5">1/1.8", 4.0 megapixel, progressive scan, CMOS</td>
</tr>
<tr>
<td>Lens</td>
<td colspan="5">2.8-12mm@F1.2, AF automatic focusing and motorized zoom lens</td>
</tr>
<tr>
<td>Iris</td>
<td colspan="5">Auto aperture</td>
</tr>
<tr>
<td rowspan="2">DORI Distance</td>
<td>Lens (mm)</td>
<td>Detect (m)</td>
<td>Observe (m)</td>
<td>Recognize (m)</td>
<td>Identify (m)</td>
</tr>
<tr>
<td>2.8-12</td>
<td>42-180</td>
<td>16.8-72</td>
<td>8.4-36</td>
<td>4.2-18</td>
</tr>
<tr>
<td>Angle of View (H)</td>
<td colspan="5">35.6°~107.9°</td>
</tr>
<tr>
<td>Angle of View (V)</td>
<td colspan="5">20.4°~75.4°</td>
</tr>
<tr>
<td>Angle of View (O)</td>
<td colspan="5">43.8°~140.3°</td>
</tr>
<tr>
<td>Shutter</td>
<td colspan="5">Auto/Manual, 1 ~ 1/100000s</td>
</tr>
<tr>
<td>Min. Illumination</td>
<td colspan="5">Colour:0.0005lux (F1.2, AGC ON)<br>0 lux with IR</td>
</tr>
<tr>
<td>WDR</td>
<td colspan="5">120dB</td>
</tr>
<tr>
<td>Day/Night</td>
<td colspan="5">IR-cut filter with auto switch (ICR)</td>
</tr>
<tr>
<td colspan="6">Video</td>
</tr>
<tr>
<td>Video Compression</td>
<td colspan="5">Ultra 265,H.265,H.264,MJPEG</td>
</tr>
<tr>
<td>Frame Rate</td>
<td colspan="5">4MP(2688*1520),Max 30fps</td>
</tr>
<tr>
<td>9:16 corridor mode</td>
<td colspan="5">Supported</td>
</tr>
<tr>
<td>ROI</td>
<td colspan="5">Supported</td>
</tr>
<tr>
<td>Video stream</td>
<td colspan="5">Triple streams</td>
</tr>
<tr>
<td>OSD</td>
<td colspan="5">Up to 8 OSDs</td>
</tr>
<tr>
<td>Privacy Mask</td>
<td colspan="5">Supported</td>
</tr>
<tr>
<td colspan="6">Smart</td>
</tr>
<tr>
<td>General Function</td>
<td colspan="5">Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication</td>
</tr>
<tr>
<td colspan="6">Audio</td>
</tr>
<tr>
<td>Audio Compression</td>
<td colspan="5">G.711U,G.711A</td>
</tr>
<tr>
<td>Voice intercom</td>
<td colspan="5">Supported</td>
</tr>
<tr>
<td>Sampling Rate</td>
<td colspan="5">8KHZ</td>
</tr>
<tr>
<td colspan="6">Storage</td>
</tr>
<tr>
<td>Edge Storage</td>
<td colspan="5">Micro SD, up to 256 GB</td>
</tr>
<tr>
<td colspan="6">Network</td>
</tr>
<tr>
<td>Protocols</td>
<td colspan="5">L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,DNS,DDNS,NTP,FTP,UPnP,HTTP,SNMP,SIP,802.1X,HTTPS</td>
</tr>
<tr>
<td>Compatible Integration</td>
<td colspan="5">ONVIF,IMOS</td>
</tr>
<tr>
<td colspan="6">Interface</td>
</tr>
<tr>
<td rowspan="2">Audio I/O</td>
<td colspan="5">Audio cable</td>
</tr>
<tr>
<td colspan="5">1/1</td>
</tr>
<tr>
<td>Alarm I/O</td>
<td colspan="5">2/1</td>
</tr>
<tr>
<td>Network</td>
<td colspan="5">1 x RJ45 10M/100M Base-TX Ethernet</td>
</tr>
<tr>
<td>Serial Port</td>
<td colspan="5">1 RS485</td>
</tr>
<tr>
<td colspan="6">General</td>
</tr>
<tr>
<td rowspan="3">&nbsp;<br>Power<br>&nbsp;</td>
<td colspan="5">AC24V±25%, DC12V(-10%~+25%), PoE(IEEE802.3at)</td>
</tr>
<tr>
<td colspan="5">Power consumption: 13.3W</td>
</tr>
<tr>
<td colspan="5">Support reverse polarity protection, Overvoltage and overcurrent protection</td>
</tr>
<tr>
<td>Dimensions (Ø x H)</td>
<td colspan="5">Φ306.4×104.1×98.4mm(Φ12.1’’x4.1’’x3.9’’)</td>
</tr>
<tr>
<td>Weight</td>
<td colspan="5">1.65kg(3.64lb）</td>
</tr>
<tr>
<td>Working Environment</td>
<td colspan="5">-30℃~60℃(-22°F ~ 140°F),≤95%RH</td>
</tr>
<tr>
<td>IR</td>
<td colspan="5">50m (164ft)</td>
</tr>
<tr>
<td>Vandal Resistant</td>
<td colspan="5">IK10</td>
</tr>
</tbody>
</table>

Характеристики

Объектив: 2.8 мм — 12 мм
Исполнение: Уличное
Материал корпуса: Металл
Рабочая температура: -30°C до +60°C
Разрешение: 4 Мп
Наличие MicroSD: Да
Тип объектива: Моторизованный вариофокальный
Дальность ИК-подсветки: 50 м
Наличие микрофона: Нет
Бренд: Uniview
