<table>
<tbody>
<tr>
<td colspan="2" width="671">Gateway</td>
</tr>
<tr>
<td width="179">Model</td>
<td width="491">WI-AC500</td>
</tr>
<tr>
<td width="179">Hardware Version</td>
<td width="491">V1</td>
</tr>
<tr>
<td colspan="2" width="671">Hardware</td>
</tr>
<tr>
<td width="179">Interface</td>
<td width="491">6*10/100/1000M/2500M Base-T Ethernet ports. (Default: 1 x LAN port，4 x LAN/WAN ports，1 x WAN ports) 1 x RJ45 Console Ports.</td>
</tr>
<tr>
<td width="179">CPU</td>
<td width="491">4 Core@2.00GHz</td>
</tr>
<tr>
<td width="179">RAM</td>
<td width="491">16GB</td>
</tr>
<tr>
<td width="179">ROM</td>
<td width="491">32GB SSD</td>
</tr>
<tr>
<td width="179">AP Unified Configuration</td>
<td width="491">500APs</td>
</tr>
<tr>
<td width="179">Recommended Bandwidth</td>
<td width="491">Speed Up to 2Gbps</td>
</tr>
<tr>
<td width="179">Power Supply</td>
<td width="491">100-240V 50/60Hz</td>
</tr>
<tr>
<td width="179">Power Consumption</td>
<td width="491"><15W</td>
</tr>
<tr>
<td width="179">Dimensions</td>
<td width="491">440mm * 220mm * 45mm</td>
</tr>
<tr>
<td width="179">Environment</td>
<td width="491">Temperature: -20℃～+55℃ (working), -40℃～+70℃ (storage) Humidity (non-condensing): 5% to 90% (working), 5% to 95% (storage)</td>
</tr>
<tr>
<td colspan="2" width="671">Software Features</td>
</tr>
<tr>
<td width="179">Network Access</td>
<td width="491">PPPoE dial-up, DHCP client, static IP</td>
</tr>
<tr>
<td width="179">Routing</td>
<td width="491">Static routing, policy-based routing, carrier address routing, active/standby mode, load balancing based on source address, flow-based load balancing, port-based weighted load balancing of data streams.</td>
</tr>
<tr>
<td width="179">Security</td>
<td width="491">ACL, DHCP static assignment, MAC address filtering dynamic ARP, static ARP binding, NAT, port mapping</td>
</tr>
<tr>
<td width="179">Other Protocols</td>
<td width="491">DHCP Server, DHCP Client, DHCP Option43/138, DNS Server, DDNS</td>
</tr>
<tr>
<td width="179">Application Recognition</td>
<td width="491">Support WAN Load Balancing Supports the ONVIF protocol Support 802.1Q VLAN TAG Support SD-LAN</td>
</tr>
<tr>
<td width="179">Flow Control</td>
<td width="491">Support custom flow control polices, IP-based automatic bandwidth assignment</td>
</tr>
<tr>
<td width="179">Traffic Audit</td>
<td width="491">Real-time traffic audit, IP Traffic visualization</td>
</tr>
<tr>
<td width="179">Authentication</td>
<td width="491">Captive Portal: One Key Auth, Pre-Shared Password Local User Auth, Voucher, Facebook, SMS Auth, RADIUS Auth, Summary for Captive Portal,</td>
</tr>
<tr>
<td width="179">VPN</td>
<td width="491">Open VPN /PPTP/L2TP / IPsec</td>
</tr>
<tr>
<td width="179">Behavior Management</td>
<td width="491">Time-based and IP policy-based access control, website filtering</td>
</tr>
<tr>
<td width="179">AP Management</td>
<td width="491">Support Auto AP Discovery, RF optimization, Batch configuration, Overview View, Multi-SSID configuration, SSID hiding, channel setting, Tx power setting, AP online upgrade, STA blacklist and whitelist</td>
</tr>
<tr>
<td width="179">Management</td>
<td width="491">Support local management with web Support remote management with Wi-Tek Cloud platform</td>
</tr>
</tbody>
</table>
Характеристики
Бренд: Wi-Tek
Количество портов 1000Mbps: 6
