UAC-T132-F28 HD видеокамера

<table width="100%">
<tbody>
<tr>
<td width="20%"><strong>Model</strong></td>
<td width="40%"><strong>UAC-T132-F28</strong></td>
<td width="40%"><strong>UAC-T132-F40</strong></td>
</tr>
<tr>
<td colspan="3">Sensor</td>
</tr>
<tr>
<td>Pixel</td>
<td colspan="2">2MP</td>
</tr>
<tr>
<td>Size</td>
<td colspan="2">1/3.2"</td>
</tr>
<tr>
<td>Minimum illumination</td>
<td colspan="2">0.02 lux (F2.0, AGC ON)<br>0 lux (IR ON)</td>
</tr>
<tr>
<td colspan="3">Lens</td>
</tr>
<tr>
<td>Lens</td>
<td>2.8mm</td>
<td>4.0mm</td>
</tr>
<tr>
<td>Lens mount</td>
<td colspan="2">M12</td>
</tr>
<tr>
<td>Angle of view</td>
<td>H: 99.7° V: 55.1° D: 117.1°</td>
<td>H: 87.7° V: 47.6° D: 106.9°</td>
</tr>
<tr>
<td colspan="3">Illuminator</td>
</tr>
<tr>
<td>Illuminator</td>
<td colspan="2">One IR illuminator</td>
</tr>
<tr>
<td>Illumination distance</td>
<td colspan="2">20m</td>
</tr>
<tr>
<td>Lifetime</td>
<td colspan="2">≥60,000 hours</td>
</tr>
<tr>
<td colspan="3">Video</td>
</tr>
<tr>
<td>Resolution</td>
<td colspan="2">1080P: 1920(H)×1080(V)<br>720P: 1280(H) ×720(V)</td>
</tr>
<tr>
<td>Frame rate</td>
<td colspan="2">TVI/AHD/CVI: 1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps<br>CVBS: PAL, NTSC</td>
</tr>
<tr>
<td>Shutter time</td>
<td colspan="2">PAL: 1/25s-1/50000s<br>NTSC: 1/30s–1/50000s</td>
</tr>
<tr>
<td colspan="3">Image</td>
</tr>
<tr>
<td>Exposure mode</td>
<td colspan="2">Four modes: Global (default), BLC, HLC, DWDR</td>
</tr>
<tr>
<td>Day/Night</td>
<td colspan="2">Three modes: Auto (default), Day, Night</td>
</tr>
<tr>
<td>Digital noise reduction</td>
<td colspan="2">2D/3D</td>
</tr>
<tr>
<td>White balance</td>
<td colspan="2">Two modes: Auto (default), Manual</td>
</tr>
<tr>
<td>WDR</td>
<td colspan="2">DWDR</td>
</tr>
<tr>
<td>Smart IR</td>
<td colspan="2">Support</td>
</tr>
<tr>
<td>Flip</td>
<td colspan="2">Supports 180° horizontal flip, 180° vertical flip</td>
</tr>
<tr>
<td>Defog</td>
<td colspan="2">N/A</td>
</tr>
<tr>
<td colspan="3">Audio</td>
</tr>
<tr>
<td>Microphone</td>
<td colspan="2">N/A</td>
</tr>
<tr>
<td>Camera audio</td>
<td colspan="2">N/A</td>
</tr>
<tr>
<td colspan="3">Interface</td>
</tr>
<tr>
<td>Power</td>
<td colspan="2">5.5mm power interface</td>
</tr>
<tr>
<td>Video output</td>
<td colspan="2">BNC, supports TVI/AHD/CVI/CVBS</td>
</tr>
<tr>
<td colspan="3">Operating environment</td>
</tr>
<tr>
<td>Temperature</td>
<td colspan="2">-20°C to 60°C (-4°F to 140°F)</td>
</tr>
<tr>
<td>Humidity</td>
<td colspan="2">≤95% (RH, non-condensing)</td>
</tr>
<tr>
<td>Surge protection</td>
<td colspan="2">4kV</td>
</tr>
<tr>
<td>Ingress protection</td>
<td colspan="2">N/A</td>
</tr>
<tr>
<td colspan="3">General</td>
</tr>
<tr>
<td>Power</td>
<td colspan="2">DC 12V (±25%), with reverse polarity protection, Max 1.9W</td>
</tr>
<tr>
<td>Dimensions</td>
<td colspan="2">Φ85mm*72mm (diameter*height)</td>
</tr>
<tr>
<td>Material</td>
<td colspan="2">Plastic</td>
</tr>
<tr>
<td>Weight</td>
<td colspan="2">89.3g (0.20lb)</td>
</tr>
<tr>
<td colspan="3">Certification</td>
</tr>
<tr>
<td>EMC</td>
<td colspan="2">CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035)<br>FCC (FCC 47 CFR part15 B)</td>
</tr>
<tr>
<td>Safety</td>
<td colspan="2">CE-LVD (EN 62368-1)</td>
</tr>
<tr>
<td>Environment</td>
<td colspan="2">CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)</td>
</tr>
</tbody>
</table>

Характеристики

Разрешение: 2 мп
Рабочая температура: -20°C to 60°C
Материал корпуса: Пластик
Объектив: 2.8 мм
Наличие микрофона: Нет
Наличие MicroSD: Нет
Тип объектива: Фиксированный
Дальность ИК-подсветки: 20 м
