IPC2105SB-ADF16KM-I0 Видеокамера

<table width="100%">
<tbody>
<tr>
<td colspan="7" width="70%">IPC2105SB-ADF16KM-I0</td>
</tr>
<tr>
<td colspan="8">Camera</td>
</tr>
<tr>
<td>Sensor</td>
<td colspan="7">1/2.7", 5.0 megapixel, progressive scan, CMOS</td>
</tr>
<tr>
<td>Minimum Illumination</td>
<td colspan="7">Colour: 0.01lux (F2.0, AGC ON) <br>0 lux with IR on</td>
</tr>
<tr>
<td>Day/Night</td>
<td colspan="7">IR-cut filter with auto switch (ICR)</td>
</tr>
<tr>
<td>Shutter</td>
<td colspan="7">Auto/Manual, 1 ~ 1/100000s</td>
</tr>
<tr>
<td>Adjustment angle</td>
<td colspan="2">Pan: 0° ~ 360°</td>
<td colspan="3">Tilt: 0° ~ 90°</td>
<td colspan="2">Rotate: 0° ~ 360°</td>
</tr>
<tr>
<td>WDR</td>
<td colspan="7">120dB</td>
</tr>
<tr>
<td>S/N</td>
<td colspan="7">&gt;56dB</td>
</tr>
<tr>
<td colspan="8">Lens</td>
</tr>
<tr>
<td>Lens type</td>
<td colspan="7">1.68mm@F2.0</td>
</tr>
<tr>
<td>Iris</td>
<td colspan="7">Fixed</td>
</tr>
<tr>
<td>Field of View (H)</td>
<td colspan="7">180°</td>
</tr>
<tr>
<td>Field of View (V)</td>
<td colspan="7">100°</td>
</tr>
<tr>
<td>Field of View (O)</td>
<td colspan="7">180°</td>
</tr>
<tr>
<td colspan="8">DORI</td>
</tr>
<tr>
<td rowspan="2">DORI Distance</td>
<td>Lens (mm)</td>
<td colspan="2">Detect (m)</td>
<td>Observe (m)</td>
<td colspan="2">Recognize (m)</td>
<td>Identify (m)</td>
</tr>
<tr>
<td>1.68</td>
<td colspan="2">37.8(124.0ft)</td>
<td>15.1(49.6ft)</td>
<td colspan="2">7.6(24.8ft)</td>
<td>3.8(12.4ft)</td>
</tr>
<tr>
<td colspan="8">Illuminator</td>
</tr>
<tr>
<td>IR Range</td>
<td colspan="7">Up to 20m (66ft) IR range</td>
</tr>
<tr>
<td>Wavelength</td>
<td colspan="7">850nm</td>
</tr>
<tr>
<td>IR On/Off Control</td>
<td colspan="7">Auto/Manual</td>
</tr>
<tr>
<td colspan="8">Video</td>
</tr>
<tr>
<td>Video Compression</td>
<td colspan="7">Ultra 265, H.265, H.264, MJPEG</td>
</tr>
<tr>
<td>H.264 code profile</td>
<td colspan="7">Baseline profile, Main profile, High profile</td>
</tr>
<tr>
<td>Frame Rate</td>
<td colspan="7">Main Stream: 5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; 1280*720 Max 30fps<br>Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; <br>Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;</td>
</tr>
<tr>
<td>Video Bit Rate</td>
<td colspan="7">128 Kbps~16 Mbps</td>
</tr>
<tr>
<td>U-code</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>OSD</td>
<td colspan="7">Up to 8 OSDs</td>
</tr>
<tr>
<td>Privacy Mask</td>
<td colspan="7">Up to 4 areas</td>
</tr>
<tr>
<td>ROI</td>
<td colspan="7">Up to 8 areas</td>
</tr>
<tr>
<td>Video Stream</td>
<td colspan="7">Triple streams</td>
</tr>
<tr>
<td colspan="8">Image</td>
</tr>
<tr>
<td>White Balance</td>
<td colspan="7">Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2</td>
</tr>
<tr>
<td>Digital Noise Reduction</td>
<td colspan="7">2D/3D DNR</td>
</tr>
<tr>
<td>Smart IR</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>Flip</td>
<td colspan="7">Normal/ Flip Vertical/ Flip Horizontal/180°</td>
</tr>
<tr>
<td>Dewarping</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>HLC</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>BLC</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>Defog</td>
<td colspan="7">Digital Defog</td>
</tr>
<tr>
<td colspan="8">Intelligent</td>
</tr>
<tr>
<td>Smart intrusion prevention</td>
<td colspan="7">Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection</td>
</tr>
<tr>
<td colspan="8">Events</td>
</tr>
<tr>
<td>Basic Detection</td>
<td colspan="7">Motion detection, Ultra motion detection, Tampering alarm, Audio detection</td>
</tr>
<tr>
<td>General Function</td>
<td colspan="7">Watermark, IP address filtering, Tampering alarm, Access policy, ARP protection, RTSP authentication, User authentication</td>
</tr>
<tr>
<td colspan="8">Audio</td>
</tr>
<tr>
<td>Audio Compression</td>
<td colspan="7">G.711U, G.711A</td>
</tr>
<tr>
<td>Audio Bitrate</td>
<td colspan="7">64 Kbps</td>
</tr>
<tr>
<td>Two-way audio</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td>Suppression</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>Sampling Rate</td>
<td colspan="7">8KHZ</td>
</tr>
<tr>
<td colspan="8">Storage</td>
</tr>
<tr>
<td>Edge Storage</td>
<td colspan="7">Micro SD, up to 256GB</td>
</tr>
<tr>
<td>Network Storage</td>
<td colspan="7">ANR, NAS(NFS)</td>
</tr>
<tr>
<td colspan="8">Network</td>
</tr>
<tr>
<td>Protocols</td>
<td colspan="7">IPv4,IPv6, IGMP,, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS</td>
</tr>
<tr>
<td>Compatible Integration</td>
<td colspan="7">ONVIF (Profile S, Profile T, Profile G), API,SDK</td>
</tr>
<tr>
<td>User/Host</td>
<td colspan="7">Up to 32 users. 3 user levels: administrator, common user and operator</td>
</tr>
<tr>
<td>Security</td>
<td colspan="7">Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2 , WSSE and digest authentication for ONVIF</td>
</tr>
<tr>
<td>Client</td>
<td colspan="7">EZStation <br>EZView<br>EZLive</td>
</tr>
<tr>
<td rowspan="2">Web Browser</td>
<td colspan="7">Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above</td>
</tr>
<tr>
<td colspan="7">Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above</td>
</tr>
<tr>
<td colspan="8">Interface</td>
</tr>
<tr>
<td>Audio I/O</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td>Alarm I/O</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td>Serial Port</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td>Built-in Mic</td>
<td colspan="7">Support</td>
</tr>
<tr>
<td>Built-in Speaker</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td>WIFI</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td>Network</td>
<td colspan="7">1 RJ45 10M/100M Base-TX Ethernet</td>
</tr>
<tr>
<td>Video Output</td>
<td colspan="7">N/A</td>
</tr>
<tr>
<td colspan="8">Certifications</td>
</tr>
<tr>
<td>EMC</td>
<td colspan="7">CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035)<br>FCC (FCC 47 CFR part15 B)</td>
</tr>
<tr>
<td>Safety</td>
<td colspan="7">CE LVD (EN 62368-1)<br>CB (IEC 62368-1)<br>UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)</td>
</tr>
<tr>
<td>Environment</td>
<td colspan="7">CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU);</td>
</tr>
<tr>
<td>Protection</td>
<td colspan="7">IP67 (IEC 60529)</td>
</tr>
<tr>
<td colspan="8">General</td>
</tr>
<tr>
<td rowspan="2">Power</td>
<td colspan="7">DC 12V±25%, PoE (IEEE 802.3af)</td>
</tr>
<tr>
<td colspan="7">Power consumption: Max 5.5W</td>
</tr>
<tr>
<td>Power Interface</td>
<td colspan="7">Ø 5.5mm coaxial power plug</td>
</tr>
<tr>
<td>Dimensions (L × W × H)</td>
<td colspan="7">198× 71 × 71mm (7.8” × 2.8” × 2.8”)</td>
</tr>
<tr>
<td>Weight</td>
<td colspan="7">0.42kg (0.93lb)</td>
</tr>
<tr>
<td>Material</td>
<td colspan="7">Metal</td>
</tr>
<tr>
<td>Working Environment</td>
<td colspan="7">-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)</td>
</tr>
<tr>
<td>Strorage Environment</td>
<td colspan="7">-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)</td>
</tr>
<tr>
<td>Surge Protection</td>
<td colspan="7">4KV</td>
</tr>
<tr>
<td>Reset Button</td>
<td colspan="7">Support</td>
</tr>
</tbody>
</table>

Характеристики

Бренд: Uniview
Наличие MicroSD: Да
Разрешение: 5 мп
Рабочая температура: -30°C ~ 60°C
Объектив: 1.68 мм
Дальность ИК-подсветки: 20 м
